Automatic Horizontal Sachet Packaging Machine with PLC Control High Efficiency

Ry-160GD-Z

  • Introduction
  • Working Principle
  • Features
  • Frequently Asked Questions
Introduction

Machine Introduction

This Automatic Horizontal Sachet Packaging Machine is designed for efficient and precise powder packaging. It features a PLC touch screen control system for easy operation, allowing real-time monitoring and adjustment. The machine automatically measures, bags, and seals powder materials with high accuracy, ensuring consistent weight and airtight seals for each sachet. Built with durable 304L stainless steel and carbon steel, it offers long-lasting performance and is suitable for various powdered products. This machine is ideal for improving production efficiency and reducing manual labor in packaging processes.

Technical Parameters

Model Name

Ry-160GD-Z

Bag length

80-160mm(L)

Bag width

110-230mm(W)

Max width of roll film

230mm

Packing speed

10-50 bags/min

Measuring range

10--500 g

Gas consumption

0.73m3 /min

Power

1N+PE/50HZ/AC380V/ 2 KW

Deadwight of machine

800 kg


Working Principle

1. Material Measurement: First, the machine automatically measures the powder material using sensors and a control system. As the powder enters the bagging system, an imported pressure-sensing device ensures that the material is not overfilled.

2. Bagging and Sealing: Once the packaging bag is prepared, the machine automatically feeds the bag through the horizontal bagging machine. It then seals the bag by pressing the opening, ensuring an airtight seal.

3. Automatic Detection and Adjustment: The machine is equipped with a PLC touch screen control system, allowing real-time monitoring and adjustments throughout the packaging process to ensure consistent weight and sealing of each bag.

4. Efficient Packaging: The optimized bagging system allows the machine to quickly and accurately package the powder, reducing waste and increasing production efficiency.

5. Structure and Control: The machine features a 304L stainless steel exterior and carbon steel frame, with anti-corrosion treatment, ensuring durability and suitability for packaging various powdered materials.

Features

1. The powder material metering and packaging system consists of a horizontal sachet packaging machine and a feeding system.

2. The bag placing chute allows easy and convenient bag placement, equipped with an automatic bag pressing device.

3. Imported pressure sensing device ensures no sealing without material, saving packaging bags.

4. The bag-feeding packaging system enables faster packaging speed and more accurate weight, using high-quality components to ensure long-term stability.

5. Equipped with a color touchscreen display for easy operation and multifunctional design.

6. Machine body made of 304L stainless steel; carbon steel frame and some components treated for acid and salt corrosion resistance.

7. Material selection: most components are molded; main materials include 304 stainless steel and anodized aluminum.

8. Optional systems: coding, inkjet printing, exhaust, and punching systems.

Frequently Asked Questions

1. What products can your counting and packaging line handle?

Our machines are suitable for:

· Capsules

· Tablets

· Gummies

· Softgels

· Pills

· Effervescent tablets

Different products may require different channel configurations and feeding systems.

2. What counting accuracy can your machine achieve?

Our electronic counting machines can reach up to 99.8% counting accuracy under normal production conditions.

For sticky products such as gummies, slight deviations may occur because products can overlap during feeding.

3. Can one machine handle different bottle sizes?

Yes.

Our machines support quick bottle size changeover by adjusting guide rails, vibration channels, and bottle positioning systems.

Suitable for:

· Round bottles

· Square bottles

· PET bottles

· HDPE bottles

4. What is the production speed?

Production speed depends on:

· Product size

· Product shape

· Bottle quantity

· Machine model

Examples:

· 8-channel counter: up to 25–40 bottles/min

· 16-channel counter: up to 40–70 bottles/min

· 24/32-channel counter: higher speeds available

5. Can your machines work with gummies?

Yes.

We provide counting solutions specially designed for gummies and sticky products.

Our machines use:

· Anti-stick feeding systems

· Adjustable vibration control

· Intelligent counting sensors

6. Do you provide complete bottling lines?

Yes.

We provide complete automatic counting and bottling solutions including:

· Bottle unscrambler

· Electronic counting machine

· Desiccant inserter

· Capping machine

· Induction sealing machine

· Labeling machine

· Collection turntable

7. Are your machines CE certified?

Yes.

Most of our machines support CE certification and comply with international export standards.

Additional certifications can be discussed according to your market requirements.

8. What voltage do your machines support?

Standard power supply:

· AC 220V / 50-60Hz

We can also customize:

· 110V

· 380V

· 415V

· Different plug standards

According to your country requirements.

9. How long is the delivery time?

Normally:

· Single machine: 7–15 working days

· Complete production line: 20–30 working days

Delivery time may vary during peak seasons.

10. Do you provide installation and after-sales service?

Yes.

We provide:

· Operation manuals

· Installation videos

· Online technical support

· Remote troubleshooting

· Lifetime technical assistance

Engineers overseas service can also be arranged if needed.

11. Can the machine connect with our existing production line?

Yes.

Our machines support integration with existing packaging systems and conveyors.

We can customize:

· Conveyor height

· Signal connection

· Feeding direction

· Layout design

12. What materials are used for the machine?

Main machine material:

· SUS304 stainless steel

Product contact parts:

· SUS316 stainless steel (optional)

Machines comply with GMP-oriented pharmaceutical production requirements.

13. Do you support OEM or customized solutions?

Yes.

We support:

· OEM branding

· Customized machine size

· Customized hopper design

· Multi-language interface

· Special product handling solutions

14. Which countries have you exported to?

Our machines have been exported to:

· USA

· Canada

· Spain

· Germany

· Mexico

· Thailand

· Indonesia

· Middle East countries

· South America

And many other regions worldwide.

15. How can I get a quotation?

Please send us:

· Product photos

· Product size

· Bottle type

· Required speed

· Voltage requirement

Our engineers will recommend the most suitable solution for you.
